Product Details
The Model 3700SC Controller's unique adjustability features include user-settings for frequency, voltage and polarity outputs, providing precision ionization performance to match any static challenge. It is housed in a high strength body and provides an operation error alarm indicator, rocker on/off switch, illuminated ion pulse rate, and lockable setting key-locks.
The Model 3700SC Controller can be operated from a remote location with integrated DIN connection. The input voltage is 115 VAC, 50/60 Hz or 24 Volts DC – with variable shockless DC current output up to 14 kV.
Typical applications of the Model 3700SC include unwind/rewind, extruding, molding, sheeting, screen printing, clean room and other applications where long distance static elimination is needed without the use of forced air.
For quantities over 5 units, please contact your Jemmco Inside Service Representative at 262-512-9559.
Specifications
| Size |
8.75" (222 mm) W x 7" (178 mm) L x 2.75" (70 mm) D |
| Frequency |
Use a slow frequency setting for distance ranges of 3 feet (914 mm) or over and faster frequency settings for closer distances, e.g. 1 ft (305 mm). Optimal operating distance ranges from minimum 1 ft (305 mm) up to 3 ft (914 mm) |
| Polarity Balance |
If the static charge varies, set a balance output. If static is constant, the balance can be adjusted 80:20 in each polarity for better performance |
| Voltage |
Variable from 0-14 kV output. Set full power for 14 kV except in sensitive electronic applications |
| Input Voltage |
Standard 115 V 50/60 Hz or standard 24 V DC; optional 230 V 50/60 Hz |
| Output Voltage |
Variable 0-14 kV DC |
| Amperage |
35-volt amps starting load; 7-volt amps running |
| Alarm Indicator Light |
Flashes to indicate warning and service needed conditions |
| Remote Control |
Remote on/off and alarm signals available through DIN connector |
